Sony HX9V think 4MP not 16MP and be happy


If you think of the Sony DSC-HX9V as a 16MP camera and you look at the results in 100%, you might be unhappy. But if you think of the HX9V as a 4MP to max 8MP camera you will be much more pleased with the results.

I will try to explain in a very simplified level the why.


The Airy Disk is the smallest dot of light any lens can produce.
The diameter in microns is about 1.35 times the f/number (using the green wavelength our eyes see most brightly). So, for example, the Airy disk at f/ 4.0 is 5.4 microns across.
It is understandable now, why prime lenses have so low f/ numbers, because the lower they are the smaller is the dot of light they can put on the sensor = higher resolution.
Also these lenses have a much higher optical quality.

The 16MP 1/2.3" sensor has 57 MP/cm² pixel density —> 1.3 micron pixels,
Panasonic´s 14 MP has 50 MP/cm² —> 1.4 micron pixels
the Sony HX5 has 35 MP/cm² —> 1.7 micron pixels
the Fujifilm F31fd had 16 MP/cm² —> 2.5 micron pixels
Sony Alpha NEX-5 has 3.9 MP/cm² —> 5 micron pixels
Sony A55 has 4.4 MP/cm² —> 4.8 micron pixels

To better understand the problematic I cropped the sensor from 4608 x 3456 to 15 x 15.
Then I overlayed an Airy Disk at f/4.0  and full tele over the cropped part of the sensor.
With the size of the 16MP sensor and the f number range of the Sony lens the smallest light dot (Airy Disk) will cover already more than 9 pixel at f 4.0.
If we do an honest count we can cover the surface of nearly 16 combined pixel.

Now you understand why every camara looses resolution and detail when you zoom in.

Let´s compare that to the Sony HX5
What we crop from the sensor has the same size but a lesser density. 1.7 micron per sensor
If we do an honest count we can cover nearly 10 pixel - fascinating.


We cover nearly 16 sensors at 16MP and 10 at 10 MP. So if we wanted to have an as sharp coverage as with a 14MP APS-C sensor, then a 1MP 1/2.3" sensor will do the trick.

Here the 14MP APS-C Sony sensor what is in the NEX-3, NEX-5 and Sony A33
5 micron per sensor


After letting sink in what I just fabricate I need a drink.



here is a nice explanation how the sensor gets the pixel color information.


A closer look at the Sony 16MP sensor.
To make things easy to understand we take a 16 pixel sensor.
Above the 16 pixel sensor is the Bayer filter which covers every pixel with one R, G or B filter. Green gets the double amount of pixels to cover.
Our smallest possible light dot covers already pixel 1-3,5-7 and 9-11.
you see there is a lot of overlapping information when we move the Airy Disk just 1 pixel to get our 16MP resolution.
Our smallest possible light dot covers 1-3,5-7 and 9-11 with some overlapping of 8 and 14  you get the picture why we have smudged detail what can not be recovered especially in low contrast and low light situations.


You understand now that when we combine 1,2,5,6 then 3,4,7,8 then 9,10,13,14 and at last 11,12,15,16 we reduced our resolution from 16 to 4 but with a much more pleasing result.

from a forum post:
theranman
Although a vast oversimplification, there is an easy way to get an idea of what the noise issue is all about. Draw a square (our sensor, so to speak). Subdivide it into four. Let's say that each of the four squares represents a pixel. Now, draw another same size square. Divide it into 16. Let's say that each of those squares represents a pixel. On the face of it, you'd think that both boxes would receive the same amount of light, right? Wrong. See the problem? The square with 16 pixels has ALLLL those lines inside of it. Those lines represent the pixel walls. Those pixel walls block the downward shining light, light that would otherwise reach the sensor if they weren't there. That's noise.

VarmintCong
Here's a cross-section of D7000 that helps illustrate this point. I don't know how much it's a factor though. The light passes through those trapezoidal shaped lines before hitting the photo sensors, which you can't really see here but are at the bottom of the image.
You can also see the mirolenses on top which make sure that more photons hitting the surface of the sensor reach their intended destination.

with the Sony BSI cmos sensor the middle part (wires) are at the bottom so the light has to travel less before hitting the photosensitive part.

A look at the full 16MP resolution with ISO 200

and after reducing to 4MP, auto color correction and some sharpening


I did the same with the images of my HX5 when the originals were just not good enough.

With this little quick and dirty explanation you have now a better understanding why I think of the Sony HX9V as a 4MP camera.
